Features
- Capable of microstructure processing on complex curved surfaces with spatial angle control ;
- Equipped with terminal laser spot position and deviation monitoring for precision control ;
- Includes real-time image detection of the processing state and an AI-driven deep learning algorithm for automatic perforation assess- ment, effectively preventing wall damage ;
- Features localized optical path purification and encapsulation,mak- ing the equipment suitable for standard factory environments ;
- Adaptive feature point positioning function to compensate for part manufacturing and clamping deviations, ensuring precise alignment ;
- Integrated with an automatic door and high-precision pneumatic chuck, supporting robotic arms for fully automated loading and unload- ing operations.(optional feature)
Specifications
| Travel (X/Y/Z Axis) (mm) | 800/500/500 |
| A Axis (Rotation Range) ( ° ) | ± 110 / n×360 |
| Positioning Accuracy (X/Y/Z Axis) (mm) | 0.010 / 0.010 / 0.010 |
| A Axis (Positioning Accuracy) ( ”) | 30 / 30 |
| Repeatability Accuracy (X/Y/Z Axis)（mm） | 0.005 / 0.005 / 0.005 |
| A Axis (Repeatability Accuracy) ( ”) | 20 / 20 |
| Average Power（w） | ≥20 |
| Pulse Width | fs-level |
| Worktable Diameter（mm） | Φ 190 |
| Worktable Maximum Load（kg） | 10 |
| Weight（kg） | 7500 |
| Overall Dimensions (mm) (W × D × H) | 2300X3750X2600 |
★Customizable with Picosecond and Femtosecond
